This Kit comes with every major component needed to complete this Hybrid Off-Grid kit Install.

Rapid-Shutdown is included and this kit is compliant with Canadian Electric Code.

Mounting is sold separately because there is multiple choices. See Mounting Kits Here

The LXP-LB 12K Luxpower hybrid inverter gives you the ability to do the whole home back-up with it’s 200A service built-in. The battery bank is balanced with the solar size and production for off-grid loads.

This kit can take your home or cabin off-grid. Feel free to get an expert design and quote.

SYSTEM OVERVIEW:

• Total Solar Power: 12Panels
• Inverter Grid-Tied Power: 12 KW
• Inverter Off-Grid Power: 12 KW
• Stackable 10X: Up to 120 KW Output Power!
• Battery Storage: 31 KWH

INVERTER FEATURES:

• 12-KW, Grid-tied Inverter Power
• 12-KW, Off-grid Inverter Power
• 18-KW, PV Input Power
•  120/240V Split Phase
• Parallel up to 10 units
•  Compatible with 50/60 Hz Grid Frequency
•  3 Mppts & 4 PV inputs
•  100 – 600V PV Input Voltage
•  12kVA Rated Power Output
•  Max. charging/discharging current of 250A
•  Max. efficiency of >=97.5%
•  Battery Voltage Range 48V
•  Compatible lithium-ion, lead acid and Lead Carbon
•  Battery reverse connect protection
•  Wifi Remote Monitoring & Management
•  Intelligent energy management features

BATTERY HIGHLIGHTS:

• Soluna Lithuim Battery
• Nominal Voltage 51.2V
• Nominal Capacity 200Ah
• 6000 Cycle Life @ 90% DOD
• 10 Year Warranty
