This Kit comes with every major component needed to complete this Hybrid Off-Grid kit Install.

Rapid-Shutdown is included and this kit is compliant with Canadian Electric Code.

Mounting is sold separately because there is multiple choices. See Mounting Kits Here

The Solis hybrid inverter gives you the ability to do the whole home back-up with it’s 200A service built-in. The battery bank is balanced with the solar size and production for off-grid loads.

This kit can take your home or cabin off-grid. We off free custom sizing and design.

SYSTEM OVERVIEW:

• Total Solar Power: 40Panels
• Inverter Grid-Tied Power: 16 KW
• Inverter Off-Grid Power: 16 KW
• Stackable 6X: Up to 96 KW Output Power!
• Battery Storage: 80.5 KWH

INVERTER FEATURES:

• 16-KW, Grid-tied Inverter Power
• 16-KW, Off-grid Inverter Power
• 25.6-KW, PV Input Power
•  120/240V Split Phase
• Parallel up to 6 units
•  Compatible with 50/60 Hz Grid Frequency
•  3 Mppts & 6 PV inputs
•  100 – 550V PV Input Voltage
•  16kVA Rated Power Output
•  Max. charging/discharging current of 290A
•  Max. efficiency of >=97.5%
•  Battery Voltage Range 48V
•  Compatible lithium-ion, lead acid and Lead Carbon
•  Battery reverse connect protection
•  Wifi Remote Monitoring & Management
•  Intelligent energy management features

BATTERY HIGHLIGHTS:

• Renon Lithuim Battery
• Nominal Voltage 51.2V
• Nominal Capacity 314Ah
• 8000 Cycle Life @ 90% DOD
• 10 Year Warranty
