Fronius Primo GEN24
The Fronius Primo GEN24 boasts a wide range of features that support a sustainable, independent energy supply. Discover the key features for installers and their customers:
– Intelligent energy management
– Active cooling technology for a longer service life
– Flexible and fast installation
– Easy integration and management of Fronius or third-party components thanks to open interfaces
Technical Data
Input Data
| Number of MPP trackers | 2 |
|---|---|
|
Max. input current (Idc max)
|
22 / 12 A |
|
Max. short circuit current, module array*
|
36 / 19 A |
|
DC input voltage range (Udc min – Udc max)
|
65 – 600 V |
|
Feed-in start voltage (Udc start)
|
80 V |
|
Nominal input voltage (Udc,r)
|
400 V |
|
MPP voltage range (Umpp min – Umpp max)
|
230 – 480 V |
| Usable MPP voltage range | 65 – 480 V |
| Number of DC connections | 2+2 |
|
Max. PV generator power (Pdc max)
|
9 kWpeak |
Output Data
|
AC nominal output (Pac,r)
|
6000 W |
|---|---|
|
Max. output power (Pac max)
|
6000 VA |
| Max. grid power demand | 6000 VA |
| Max. AC output current | 27,5 A |
|
Grid connection (Uac,r)
|
1~ NPE 220/230 V |
|
AC voltage range (Umin – Umax)
|
155 – 270 V |
|
Frequency (fr)
|
50 / 60 Hz |
|
Frequency range (fmin – fmax)
|
45 – 65 Hz |
| Total harmonic distortion | <3% @Pnom (230/400VAC 50Hz) |
|
Power factor (cos φac,r)
|
0,8 – 1 ind./cap. |
| Back-up power | 1~NPE 220 V / 230 V |
| Nom. output current (220VAC) | 27,3 A |
| Nom. output current (230VAC) | 26,1 A |
Output Data PV Point
| Max continuous output power | 3000 VA |
|---|---|
|
Nom. output current (Iac max)
|
13 A |
| Grid connection | 1~NPE 220 V / 230 V |
| Frequency | 50 Hz / 60 Hz |
| Max. switchover time PV-Point | 15 s |
| Frequency in backup power mode | 53 Hz |
