PRODUCT DESCRIPTION
HIGH YIELD
- 4 MPPTs, 2 strings in parallel
- max. efficiency 98.9%
- Compatible with bifacial modules (45A Isc_max per MPPT)
- Built-in PID recovery function
SMART O&M
- Easy commissioning with cell-phone app
- Online IV curve scan and diagnosis (depending on monitoring provider)
- Fuse-free design with smart string current monitoring
LOW SYSTEM COST
- DC/AC ratio greater than 1.5
- Compatible with Al and Cu AC cables
- Flexible installation from vertical to horizontal
PROVEN SAFETY
- NEMA 4X protection rating
- Type II SPD for both DC and AC
- Compliant with cUL safety and IEEE1547, UL1741
SPECS |
|
|---|---|
| Power Output | 36kW |
| AC Voltage | 480V |
| DC Voltage | 1000V |
| Peak Efficiency | 98.7% |
| CEC Efficiency | 98.5% |
| Maximum DC Input Voltage | 1000V |
| Maximum Short Circuit DC input Current | 45A |
| Maximum Operation DC Input Current | 30A |
| Number of MPPT’s | 4 |
| MPP operating voltage window | 200-1000V |
| Connectivity | RS485 / SunSpec Modbus/ Optional: WiFi and Ethernet |
| Display | LED, Bluetooth + APP |
| Cooling Method | Smart forced air cooling |
